Model R80
Ratio ID OD VA Axial Length (mm) For Accuracy Class
Class 3 Class 1 Class 0.5
200/5A or 1A 83 125 2.5 18 33 91
5 18 47 120
10 33 91 -
15 33 - -
250/5A or 1A 83 125 2.5 18 33 63
5 18 47 76
10 33 63 -
15 33 76 -
300/5A or 1A 83 125 2.5 18 18 33
5 18 33 60
7.5 18 33 88
400/5A or 1A 83 125 2.5 18 18 33
5 18 18 33
7.5 18 18 44
10 18 33 60
15 33 33 88
500/5A or 1A 83 125 5 18 18 33
10 18 18 46
15 33 33 60
600/5A or 1A 83 125 5 18 18 33
10 18 18 28
15 18 18 46
750/5A or 1A 83 125 5 18 18 18
10 18 18 33
15 18 18 28
800/5A or 1A 83 125 5 18 18 18
10 18 18 33
15 18 18 33
1000/5A or 1A 83 127 15 18 18 18
1200/5A or 1A 80 127 15 22 22 22
1500/5A or 1A 80 127 15 22 22 22
1600/5A or 1A 80 127 15 22 22 22




Ordering Information
Required Information Example
Ratio 1000/5A
VA 10VA
Accuracy Class Class 0.5
Limit Factor
Minimum Inside Diameter 100mm
Assmbley Style RT Terminals
Assmbley Style RLx Ring with Leads 1Metre (RL1M)
Assmbley Style RTS Ring with Terminals & Screws
Assmbley Style RTF Ring with Terminals & Frame
Assmbley Style RTC Ring with Terminals & Busbar Clamp
Assembley Styles Multiple configuration RTFS
