 Medium Voltage Indoor Type
CURRENT TRANSFORMERS
Voltage Level Model Style / Dimensions LWH Aperture PDF
12kV ITL/GEMCT-12 Block   ITLGEMCT12
12Kv ITL/APL-12 Pri-Bar / 675 x 400 x 290   APL12
17.5kV IT-PTG5 Block w/Primary Fuse   IT-PTG5
17.5kV ITL/GEMCT-15 Block   ITLGEMCT15
17.5kV ITL/ABD-17 Toroid / 400 x 300 x 230 130mm ABD17
17.5kV ITL/ACI-17 Block / 338 x 148 x 256   ACI17
17.5kV ITL/ACIL-17 Block / 472 x 148 x 256   ACIL17
24kV ITL/GEMCT-24 Block   ITLGEMCT24
24Kv ITL/ABD-24 Toroid / 350 x 350 x 360 150 ABD24
24Kv ITL/ACD-24 Block / 353 x 178 x 281   ACD24
24Kv ITL/ACF-24 Block / 353 x 178 x 281   ACF24
24Kv ITL/ACJ-24 Block / 345 x 178 x 316 ACJ24
24Kv ITL/ACJL-24 Block / 472 x 178 x 316   ACJL24
24kV ITL/ACM-24 Block /446 x 260 x 400 ACM24
36kV ITL/GEMCT-36 Block   ITLGEMCT36
36Kv ITL/ACF-36 Block / 353 x 210 x 391   ACF36
36Kv ITL/ACM-36 Block / 446 x 260 x 431   ACM36
36Kv ITL/APL-36 Pri-Bar / 975 x 400 x 290   APL36
52Kv ITL/ACK-52 Block / 419 x 280 x 496   ACK52
72Kv ITL/ACK-72 Block / 418 x 310 x 686   ACK72





VOLTAGE TRANSFORMERS
Voltage Level Model Style / Dimensions LWH PDF
4.2kV ITL/PTG3 Block-No Fuse / 276 x 162 x 164 ITLPTG3
4.2kV ITL/PTG3F Block with 1 Pri-Fuse / 276 x 162 x 164 ITLPTG3F
4.2kV ITL/PTG3FF Block with2 Pri-Fuse / 276 x 162 x 164 ITLPTG3FF
12kV ITL/GEMVT-12 Block ITLGEMVT12
12Kv ITL/VCI-12 2 Pole Block / 275 x 148 x 261 VCI12
15kV ITL/PTG5 Block-No Fuse / 333 x 235 x 229 ITLPTG5
15kV ITL/PTG5F Block with 1 Pri-Fuse / 333 x 235 x 229 ITLPTG5F
15kV ITL/PTG5FF Block with2 Pri-Fuse / 333 x 235 x 229 ITLPTG5FF
17.5kV ITL/GEMVT-15 Block ITLGEMVT15
17.5kV ITL/UCI-17 1 Pole Block / 275 x 148 x 261 UCI17
24kV ITLGEMVT-24 Block ITLGEMVT24
24Kv ITL/UCJ-24 1 Pole Block / 325 x 178 x 311 UCJ24
24Kv ITL/UCL-24 1 Pole Block / 300 x 185 x 321 UCL24
24Kv ITL/UCN-24 1 Pole Block / 375 x 222 x 386 UCN24
24Kv ITL/UCS-24 1 Pole Block / 410 x 240 x 383 UCS24
24Kv ITL/VCL-24 2 Pole Block / 300 x 185 x 311 VCL24
24Kv ITL/VCN-24 2 Pole Block / 375 x 222 x 451 VCN24
24Kv ITL/VCS-24 2 Pole Block / 410 x 275 x 403 VCS24
24Kv ITL/VCT-24 2 Pole Block / 450 x 240 x 371 VCT24
36kV ITLGEMVT-36 Block ITLGEMVT36
36Kv ITL/UCN-36 1 Pole Block / 375 x 222 x 386 UCN36
36Kv ITL/UCS-36 1 Pole Block / 410 x 240 x 383 UCS36
36Kv ITL/VCN-36 2 Pole Block / 375 x 222 x 451 VCN36
36Kv ITL/VCS-36 2 Pole Block / 410 x 405 x 403 VCS36
52Kv ITL/UCS-52 1 Pole Block / 410 x 255 x 518 UCS52
72Kv ITL/UCS-72 1 Pole Block / 410 x 285 x 810 UCS72
